Many contractors in Rockhampton specify a geogrid purely by tensile strength and call it done. That approach ignores the interaction between the grid and the local soil matrix. For example, a biaxial grid that works well on the coastal sands near Yeppoon may perform poorly on the high-plasticity clays found west of the Fitzroy River. We have seen projects where the specified geogrid unravelled at the junction due to inadequate junction efficiency for the actual subgrade stiffness. A proper geogrid specification must consider the soil classification, the base course thickness, and the long-term design creep strain. Before writing the spec, we run a clasificacion de suelos to confirm the fines content. That single test determines whether a PET or PP grid is suitable and what aperture size prevents clogging. We also verify the granulometria of the fill material to ensure the geogrid interlocks correctly. On projects requiring long-term reinforcement, we combine the spec with a ensayo triaxial to obtain the stress-strain parameters for the reinforced zone.
A geogrid specified without junction efficiency data is a guess, not an engineering decision.
Scope of work
Area-specific notes
Rockhampton sits at an elevation of 13 m above sea level, but the floodplain of the Fitzroy River extends across most of the urban area. During the 2011 flood, water levels reached 8.2 m at the Rockhampton gauge, saturating subgrades for weeks. A geogrid installed in a saturated, fine-grained subgrade suffers from reduced pullout resistance and higher creep rates. If the specification ignores the saturated condition, the reinforcement can strain excessively under sustained load. We always include a partial factor for wet subgrade in the geogrid specification for any site within the 1-in-100-year flood contour. The alternative is long-term deformation that cracks the pavement or tilts the wall.
Standards used
AS 4678-2002 Earth-retaining structures, AS 1726-2017 Geotechnical site investigations, GRI-GG2 Standard test method for junction strength, AS/NZS 1170.2:2011 Structural design actions – wind
Linked services
Subgrade classification and CBR testing
We classify the subgrade soil per AS 1726 and perform in-situ CBR tests to determine the design subgrade modulus. This data directly feeds into the required geogrid tensile strength and aperture size.
Pullout and interface shear testing
Using a large-scale pullout box, we measure the interface friction angle between the geogrid and the site-specific backfill. This test validates the bond coefficient used in the wall design.
Long-term creep assessment
We conduct accelerated creep tests at elevated temperature to extrapolate the 75-year creep strain under sustained load. The result provides the RFcr factor required by AS 4678.
Typical parameters
Watch how it works
FAQ
What is the difference between a uniaxial and biaxial geogrid specification for Rockhampton?
A uniaxial geogrid has high tensile strength in one direction and is used for reinforced soil walls and steep slopes where the principal stress is vertical. A biaxial grid has similar strength in both directions and is used for base reinforcement in pavements and working platforms. In Rockhampton, uniaxial grids are common for retaining walls along the Bruce Highway, while biaxial grids are typical for industrial yards on the floodplain.
What geogrid polymer is best for the Rockhampton climate?
Polyester (PET) has lower creep and better resistance to hydrolysis than polypropylene (PP) in warm, humid climates. For permanent works in Rockhampton, we usually specify PET geogrids with a carbon-black coating for UV resistance. PP grids are acceptable for temporary works shorter than six months.
How much does a full geogrid specification and testing package cost in Rockhampton?
The cost typically ranges between AU$570 and AU$1,920 depending on the number of tests required. A basic package with subgrade classification and CBR testing is at the lower end. A full package including pullout and creep tests sits at the upper end.
Can I use a geogrid specification from a different region for my Rockhampton project?
Not safely. A specification from a temperate region will lack the partial factors for wet subgrade and high temperature that apply in Rockhampton. The same grid that works in Melbourne may creep excessively in Rockhamptons summer heat. Always tailor the spec to the local climate and the specific subgrade conditions.
